Add to Cart
| Attribute | Value |
|---|---|
| Size | 3.5 Inch TFT |
| Interface | RGB |
| Resolution | 640*480 |
| Viewing angle | ALL |
| Brightness | 800 cd/m2 |
| Operating temperature | -20~70℃ |
| Item | Standard Values | Units |
|---|---|---|
| LCD size | 3.5'' | |
| Resolution | 640(RGB)*480 | dots |
| Outline dimension | 76.84*63.84*3.26 | mm |
| Active area | 70.08(W)*52.56(H) | mm |
| Contrast Ratio | 800 | |
| Viewing angle | 85/85/85/85 | L/R/U/D |
| Luminance | 800 | cd/m2 |
| Interface | TTL&RGB 24bit | |
| Pin | 54 | pin |
| Operating temperature | -20 ~ +70 | °C |
| Storage temperature | -30 ~ +80 | °C |
